NUT FORGING

Sr
No		 Name Of Machine Capacity
1 11B5S (Foring Machine) M4~M6
2 11B6S (Foring Machine) M4~M6
3 14B5S (Forging Machine) M6~M8
4 17B5S (Forging Machine) M8~M10
5 19B5S (Forging Machine) M10~M12
6 14B6S (Forging Machine) M6~M10
7 24B6S (Forging Machine) M14~M20
8 33B6SL ( P.K.O.) Partsformer 33mm

FORGING SECTION

FORGING SECTION
NUT TAPPING

Sr
No		 Name Of Machine Capacity
1 19B (Internal Thread multi SpindleTapping Machine) M8~M14
2 24B (Internal Thread multi SpindleTapping Machine) M7 FN~M14 FN
3 11B (Internal Thread multi SpindleTapping Machine) M6 FN~M7 FN
4 14B (Internal Thread multi SpindleTapping Machine) M5 FN~M8 FN
5 M4 (Internal Thread single spindleTapping Machine) M4 Plain Nut
6 M5 (Internal Thread single spindleTapping Machine) M5 Plain Nut
7 M6 (Internal Thread single spindleTapping Machine) M6 Plain Nut
8 M8 (Internal Thread single spindleTapping Machine) M8 Plain Nut
9 M12 Spl T Nut Tapping Machine (2 Spindle) M10~M12

TPM CULTURE

TPM CULTURE
BOLT FORGING

Sr
No		 Name Of Machine
Capacity
Size Length
HEADERS
1 M6 Header Machine For Screw M4~M6 10.00~50.00
2 M6 Header Machine For Screw M4~M6 10.00~50.00
3 M6 Header Machine For Hex Bolt M4~M6 10.00~50.00
4 M6 Header Machine For Flange Screw M4~M6 10.00~50.00
5 M8 Headed Machine For Bolt M8~M10 15.00~50.00
6 M10 Header Machine For Bolt M10~M12 15.00~85.00
BOLT FORMERS
7 CBF63S (Foring Machine) M4~M6 6.00~40.00
8 17SBF3S Forging Macine M6~M12 9.00~105.00
9 17SBF4S Forging Macine M6~M12 9.00~105.00
10 10B4S Forging Machine M5~M6 10~60
11 13B3S Forging machine M6~M8 10~75
12 13B4S Forging machine M6~M8 10~75
13 19B45 Forging machine M8~M16 15.00~105.00
1 17B3S Forging machine M8~M10 10.00~75.00
2 19B45 Forging machine M8~M12 10.00~75.00

GRINDING SECTION

GRINDING SECTION

CNC MACHINING

CNC MACHINING
TRIMMING

Sr
No		 Name Of Machine Size Length
1 Trimming Machine 8 A/F 10.00~30.00
2 Trimming Machine 17 A/F 15.00~50.00
3 Trimming Machine 17 A/F 20.00~80.00

HEAT TREATMENT

HEAT TREATMENT
BOLT THREAD ROLLING

Sr
No		 Name Of Machine Size Length
1 M5 External threda Rolling Machine(Fully Auto) M4~M5 10.00~30.00
2 M6 External threda Rolling Machine(Fully Auto) M4~M6 8.00~50.00
3 M6 External threda Rolling Machine(Fully Auto) M4~M6 8.00~50.00
4 M10 External threda Rolling Machine(Fully Auto) M6~M10 15.00~85.00
5 M12 External threda Rolling Machine(Fully Auto) M8~M12 15.00~50.00
6 M6 External threda Rolling Machine(Manual) M6~M8 6.00~50.00
7 M10 External threda Rolling Machine(Manual) M8~M12 6.00~50.00
8 M6 Spl Thread Rolling Machine M6 9.00~15.00
9 M6 External thread rolling machine (Fully Auto) M6 8.00~50.00
10 M8 External thread rolling machine (Fully Auto) M8 15.00~50.00

HEAT TREATMENT

HEAT TREATMENT
HEAT TREATEMENT

Sr
No		 Name Of Machine Size
1 Continuous Shekher Earth Furnace M6~M16
2 Continuous Shekher Earth Furnace M6~M16
SURFACE TREATEMENT

Sr
No		 Name Of Machine Size
1 Automatic plating plant 300 Tons Per Month
2 Alkaline Zink Iron Plating Barrel Not Applicable
3 Chiller For Alkaline Barrel Not Applicable
4 Hydrogen embritelement Not Applicable
5 Dryer Not Applicable
6 Chemical Lab For tesing of plating chemicals 1

SURFACE TREATMENT

SURFACE TREATMENT
CENTERLESS GRINDING

Sr
No		 Name Of Machine Size
1 Centerless Grinding machine Not Applicable
2 Centerless Grinding machine Not Applicable
